4-1/2 in Sand-Service Swab Cup
Dimensions and reference
- Reference part: 57467
- Outer diameter: 4.062 in
- Inner diameter: 2.420 in
- Referenced casing sizes: 4-1/2 in or 4-3/4 in
Application
- Tubing and casing swabbing, fluid lifting and related well-service assemblies.
Sand-service swab cup
This 4-1/2-inch sand-service swab cup is used in tubing and casing swabbing, fluid lifting and related well-service assemblies. The product reference is 57467.
Dimensions and part reference
- Reference part: 57467
- Outer diameter: 4.062 in (103.17 mm)
- Inner diameter: 2.420 in (61.47 mm)
- Referenced casing sizes: 4-1/2 in or 4-3/4 in
The 4-1/2-inch designation is the nominal casing reference, not the measured cup diameter. Compare the outer and inner diameters with your existing cup and mandrel interface. The casing weight and actual bore dimensions are also needed when checking fit.
Replacement and manufacturing enquiries
Send the part number, drawing or photos of your existing cup, together with the required quantity. For a different assembly, include the mandrel dimensions and any insert or reinforcement requirements.
For material selection, include the service fluid, temperature and pressure. If your order requires particular inspection records or accompanying documents, include these with the enquiry.
